1uF 1000VDC Resonant Capacitor

Product Categories

Guangdong Huayu Electronic Company Limited

Contact Now

Name: 1uF 1000VDC Resonant Capacitor
Brand: GDHY
Price: 3 USD

Brand Name : GDHY

Model Number : C42-0.36UF/3000V

Place of Origin : CHINA

MOQ : 5KPCS

Price : USD3/PC

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 1000PCS/MONTH

Delivery Time : 14DAYS

Certification : ISO,SGS

Capacity : 0.36uF

Voltage : 3000VDC

Application : switching device in power electronics

Model : C42302364JP34-01

Brand : GDHY

Packing : Plastic Case

Terminal : CP Wire

Capacity Tolerance : ±5%(J); ±10%(K)

Material : Polypropylnen Film

Series : Resonant Capacitor

Place Of Original : China

Contact Now

Technical Parameter

Reference Standards	GB/T 17702 IEC 61071
Operating Temperature Range	Max.Operating temperature,Top max:+105℃ Upper category temperature:+85℃ Lower category temperature:-40℃
Capacity Range	0.1μF～8.0μF
Rated Voltage	400VDC～3000VDC
Capacity Tolerance	±5%(J); ±10%(K)
Test Voltage between Terminals	1.5Ur(DC)60S 20℃
Test Voltage btw Terminals & Case	1000+2×Ur/√2(VAC) 50Hz 60S(1min 3000V)
Dissipation Factor	tgδ≤0.0005 C≤1μF f=10KHz at 20℃ tgδ≤0.0010 C≥1μF f=10KHz at 20℃
Insulation Resistance	C≤0.33μF Rs≥15000MΩ(20℃ 100VDC 60S) C>0.33 μF RsC≥5000S (20℃ 100VDC 60S)
Flame Retardation	UL94V-0
Life Expectancy	100000hrs ( Ur hotspot ≤ 85℃)

Application

● Widely used in series circuits or parallel resonant circuits of power electronic devices.

● Also applied to the peak voltage of the switching device in power electronics, peak current absorption protection.

Features

● Plastic shell encapsulation, epoxy resin sealed

●Tinned copper wire, small size, easy installation

● High voltage resistance, small dissipation factor (tgδ)

● Low ESL and ESR, low temperature rise

● High pulse current, high dV/dt, high stability, self healing

Product Picture
