Mkp X2 Class Anti-Interference 0.47uf 310v 27.5mm Suppression Capacitor

Name: Mkp X2 Class AntiInterference 047uf 310v 275mm Suppression Capacitor
Brand: GDHY
Price: 1 USD

Brand Name : GDHY

Model Number : X2 0.47UF 310V P=27.5MM

Certification : CQC, KC, VDE, UL, SGS ETC

Place of Origin : GUANGZHOU, CHINA

MOQ : 30KPCS

Price : PLEASE CONTACT US FOR MORE DETAILS

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : 1000 KPCS/ MONTH

Delivery Time : 15 DAYS

Packaging Details : CARTON

MODEL : X2 0.47UF 310V P=27.5MM

MATERIAL : METALLIZED POLYPROPYLENE FILM DIELECTRONIC

CAPACITANCE : 0.47UF

RATED AC VOLTAGE : 310VAC

RATED DC VOLTAGE : 630VDC

TOLERANCE : ±10%

OPERATING TEMPERATURE RANGE : -40℃～110℃

PITCH : 27.5MM

DIMENSION : 31*18*9 MM

Reference Standards : GB/T 14472(IEC 60384-14)

PLACE OF ORIGIN : GUANGDONG, CHINA

SUPPLIER TYPE : ORIGINAL MANUFACTURER

TYPE : POWER ELECTROMAGNETIC INTERFERENCE SUPPRESSION CAPACITOR

COLOR : YELLOW

CHARACTERISTICS : WITHSTAND OVERVOLTAGE SHOCKS

CERTIFICATION : CQC, KC, ENEC-VDE, VDE, UL/CUL, ETC

APPLICATION : ANTI-INTERFERENCE OCCASIONS

OEM/ODM : YES

MEADIA AVAILABLE : DATASHEET

Contact Now

Mkp X2 Class Anti-Interference 0.47uf 310v 27.5mm Suppression Capacitor MKP(X2-CLASS) 0.47UF/310V P=27.5MM EPCOS/TDK SAFETY CAPACITORS INTERFERENCE SUPPRESSION CAPACITOR MKP-X2

Technical Parameter

Reference Standards	GB/T 14472(IEC 60384-14)
Climate Category	40/110/56/B
Operating Temperature Range	-40℃~110℃
Capacitance	0.47μF
Rated AC voltage	310VAC
Cap. Tor	±10% (K)
Withstand voltage	Vt-t:4.3UR (VDC), 2S Vt-c:2100VAC,1min
Insulation Resistance	C≤0.33μF R≥15000MΩ ( 20℃ 100VDC 1Min) C>0.33μF RCN≥5000S ( 20℃ 100VDC 1Min)
Dissipation factor	≤0.0010(1KHz,20℃ ) ≤0.0020(10KHz,20℃)

Specification download (datasheet): MKP-X2.pdf

Application

It is mainly used in power supply cross circuit and other anti-interference occasions.

Features

● Metallized polypropylene film material

● Enclosed in a plastic sealed with epoxy resin

● Non-inductive winding construction

● Withstand overvoltage shocks

● Good appearance consistency

● Excellent flame retardant property

Product picture
