EMI Suppression X2 Capacitor Non Inductive Winding Structure 0.68uF 684nF

Name: EMI Suppression X2 Capacitor Non Inductive Winding Structure 068uF 684nF
Brand: GDHY
Price: 0.1 USD

Quality EMI Suppression X2 Capacitor Non Inductive Winding Structure 0.68uF 684nF wholesale

Brand Name : GDHY

Model Number : X2 684K310V P22.5

Certification : CQC, KC, VDE, UL, SGS ETC

Place of Origin : GUANGZHOU, CHINA

MOQ : 20KPCS

Price : 0.1 USD/ PCS

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : 1000 KPCS/ MONTH

Delivery Time : 15DAYS

Packaging Details : CARTON

OPERATION TEMPERATURE : -40℃～110℃

TOLERANCE : ±10%

PITCH : 22.5MM

MATERIAL : polypropylene film

CAPACITANCE : 684nf

APPLICATION : Widely use in Stop of Power Electromagnetic

RATED AC VOLTAGE : 310VAC

PLACE OF ORIGIN : GUANGZHOU, CHINA

RATED DC VOLTAGE : 630VDC

DIMENSION : 32*20*11MM

MODEL : X2 564K310V P22.5

CHARACTERISTICS : Power Electromagnetic Interference; self-cure

OEM/ODM : Both OEM and ODM

SUPPLIER TYPE : MANUFACTURER

COLOR : YELLOW

ENCAPSULATION : PACKING IN FLAME RETARDANT EPOXY

CERTIFICATION : KC, VDE, UL, SGS ETC,CQC

PACKAGE TYPE : Plastic shell encapsulation

Contact Now

0.68uF 684nF EMI suppression X2 Capacitor Non-inductive winding structure

Technical Parameter

Reference Standards	GB/T 14472 (IEC 60384-14)
Climate Category	40/110/56/B
Operating Temperature Range	-40℃~+110℃
Capacity Range	0.68μF/684uF
Rated Voltage	310VAC
Capacity Tolerance	±10%(K)
Withstand voltage	Vt-t:4.3UR (VDC), 2S Vt-c:2100VAC,1min
Insulation Resistance	C≤0.33μF R≥15000MΩ ( 20℃ 100VDC 1Min) C>0.33μF RCN≥5000S ( 20℃ 100VDC 1Min)

Specification download: MKP-X2-P - smaller size.pdf

Application

Specially designed for Suppression of Power Electromagnetic Interference, widely applied to anti-interference situations such as power supply across lines and other AC field.

Features

● Metallized polypropylene film dielectronic

● Non-inductive winding structure

● Plastic shell encapsulation

● Withstand over voltage shocks

● Good appearance consistency

Product picture
