Name: CBB81 682J1600V P15 Polypropylene Film Capacitor Condensador Electric Mosquito Swatters
Brand: GDHY
Price: 1 USD

Brand Name : GDHY

Model Number : CBB81 682J1600V P15

Certification : SGS,ISO

Place of Origin : GUANGZHOU, CHINA

MOQ : 100KPCS

Price : PLEASE CONTACT US FOR MORE DETAILS

Payment Terms : Western Union, T/T, MoneyGram

Supply Ability : 1KK PCS/MONTH

Delivery Time : 15 WORKING DAYS

Packaging Details : PLASTIC BAG

SERIES : CBB81

TYPE : HIGH VOLTAGE METALLIZED POLYPROPYLENE FILM/FOIL CAPACITORS

CAPACITY : 0.0068uf/682

RATED VOLTAGE : 1600V

SIZE : W*H*TMAX 18*7.5*11.5MM

PITCH : 15MM

FEATURES : LOW-LOSS AT HIGH-FREQUENCY

MATERIAL : METALLIZED POLYPROPYLENE FILM FOIL DIELECTRIC

Contact Now

CBB81 682J1600V P15 POLYPROPYLENE FILM CAPACITOR ELECTRIC MOSQUITO SWATTERS HIGH CURRENT CIRCUITS

Model number	T6821600-D-15-1R
Reference Standards	GB/T 14579(IEC 60384-17)
Climate Category	40/085/21
Operating Temperature Range	-40℃ to +85℃, Tmax 105℃
Capacity	0.0068UF/682
Rated Voltage	1600V
Pitch	15MM
Dimension (WHT)	187.511.5MM
Capacity Tolerance	±5%(J);±10%(K)
Withstand voltage	Vt-t:1.75UN 5S (at20 ±5%)
Dissipation Factor	tgδ≤0.0010 (20℃, 1KHz)
Maximum Pulse Rise Time (dv/dt)	30000(V/μS)
Insulation Resistance	>50000MΩ (at 20℃ 1Min)

Specification download: CBB81.pdf

Application

● Widely used in high-frequency DC/AC and pulse circuits.

● Ideal for high pulse and high current circuits, such as CRT deflection for R-F generators and pulse-forming networks.

● Can be applied in AC/Motor, power, lighting, air conditioner, high voltage, fan, automobile, display, color TV reverse circuits.

Feature

● Metallized polypropylene film foil dielectric

● Non-inductively wound.

● Excellent frequency and temperature characteristics.

● High-insulation resistance, self-healing effect.

● With copper-clad steel and epoxy resin coating.

● High stability of capacitance.

● Resistance to high voltage, small tgδ and inherent temperature rise

● Good performance

Product Picture
