21UF 500VAC ALCON FP-10-400 Power Film Capacitor Resonant Circuits EV Wireless Chargers

Name: 21UF 500VAC ALCON FP10400 Power Film Capacitor Resonant Circuits EV Wireless Chargers
Brand: GDHY
Price: 1 USD

Quality 21UF 500VAC ALCON FP-10-400 Power Film Capacitor Resonant Circuits EV Wireless Chargers wholesale

Brand Name : GDHY

Model Number : C41501216KBB3501-01

Certification : SGS,ISO

Place of Origin : GUANGZHOU, CHINA

MOQ : 30 PCS

Price : PLEASE CONTACT US FOR DETAILS

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : 1000 PCS / MONTH

Delivery Time : 14 DAYS

Packaging Details : CARTON WITH FOAM BOX AND ANIT-CORRISON PROTECT.

BRAND : GDHY

SUPPLIER TYPE : ORIGINAL MANUFACTURER

EXPERIENCE : OVER 22 YEARS

PRODUCT TYPE : WATER COOLED RESONANT CAPACITOR

MODEL NUMBER : C41501216KBB3501-01

CAPACITANCE : 21μF

RATED VOLTAGE : 500VAC

TOLERANCE : ±10%

DIMENSION : 100*100*54MM

ADVANTAGE : EXCELLENT HEAT DISSIPATION

Contact Now

21UF 500VAC ALCON FP-10-400 Power Film Capacitor Resonant Circuits EV Wireless Chargers C41 BB3 21UF/500VAC ALCON FP-10-400 POWER FILM CAPACITORS RESONANT CIRCUITS EV WIRELESS CHARGERS

Technical Parameter

Reference Standards	GB/T 3984-2004 IEC 60110.1
Rated Capacitance	21μF
Rated Power	500kVar
Rated Voltage	500VAC
Capacity Tolerance	±10%
Operating Temperature Range	-40℃～+85℃
Test Voltage between Terminals	1.5UNAC 10s
Test Voltage between Terminals	2~3.5UNDC 10s at 25℃±5℃
Dissipation Factor	tgδ≤5×10-4 at 25℃±5℃,1kHz
Insulation Resistance	R•C≥3000s,at 100VDC,25℃±5℃,60s
Life Expectancy	100000h at UN and 70℃,30000h at Urms
Life Expectancy	100000h at UN and 70℃,30000h at Urms

Specification download: C41-BB3.pdf

Application

● This series product is widely used in high power and high frequency resonant devices.

● Can also be applied in induction heating, welding equipment, medical imaging, wireless power transfer, electric vehicle charging,etc.

Feature

● Conduction water-cooled

● Polypropylene dielectric

● Excellent heat dissipation with stable performance and approved quality.

● Low DF, ESL and ESR

● High voltage, high frequency and high dV/dt; high current resistance

● Operating temperature ranges from -40℃～85℃

Product Picture
