1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm

Name: 1μF 400VDC CBB Polypropylene Film Capacitor Pitch 2005mm
Brand: GDHY
Price: 0.5 USD

Quality 1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm wholesale

Brand Name : GDHY

Model Number : CBB22-105J400V-20RUN-3U

Certification : SGS,ISO

Place of Origin : GUANGZHOU, CHINA

MOQ : 10KPCS

Price : 0.5 USD/ PCS

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : 1000 KPCS

Delivery Time : about 14 DAYS

Packaging Details : plastic bag and carton

Place Of Origin : Guangzhou, China

Supplier Type : Original Manufacturer

Classification : Polypropylene Film Capacitor

Model number : B1050400-D-20-3U

material : Metallized polypropylene film

Operating Temperature Range : -40℃～85℃

Capacitance : 1UF

Capacity Tolerance : ±5%

Rated DC Voltage : 400VDC

Pitch : 20±0.5mm

height : 7.5mm

width : 23mm

thickness : 12.5mm

Contact Now

Original manufacturer, 1μF 400VDC, Polypropylene Film Capacitor,Pitch 20+-0.5mm

1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm

Technical Parameter

Reference Standards	GB/T 10190(IEC 60384-16)
Climate Category	40/085/21
Operating Temperature Range	-40°℃~85°℃
Capacitance	1μF
Rated Voltage	400VDC
Capacity Tolerance	±5%
Withstand voltage	Vtet:1.6UN 5S (at20±5℃)
Insulation Resistance	C≤0.33uF R≥100000MQ(at20°℃ 100VDC 1Min) C>0.33 uF RCN≥30000s (at20℃ 100VDC 1Min)

Specification download: CBB22.pdf

Application

Widely used in High Frequency, DC, AC, Pulse Circuits. S-correction circuits of the display device

Features

● Metallized polypropylene film dielectric

● Non-inductive winding structure

● Flame retardant epoxy resin powder encapsulation

● Resistance to high voltage, small tg6,low temperature rise

Product picture

1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm

Product shape

1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm

Production

1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm

Workshop& Equipment

1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm

Packing method

1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm

Certificate

1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm

Exhibition

1μF 400VDC CBB Polypropylene Film Capacitor Pitch 20+-0.5mm
